    To change Curtin control zone (CTR) airspace status from CTR to RA2 and to replace R801 with segregated airspace volumes that better reflect Defence usage.

    The issue

    • Change Curtin CTR airspace status from CTR to RA2.
    • Replace R801 with segregated airspace volumes that better reflect Defence usage and provide airspace efficiencies.

    This proposal is being developed for inclusion in AIRAC 2512 publication 27 November 2025. Activations of Curtin airspace to support military exercises in Northern Australia in 2025 will be as per the AVSEF consultation currently open on the AVSEF Forum.

    Purpose

    To amend airspace in the immediate vicinity of Curtin aerodrome to achieve airspace efficiencies.

    Proposal

    The proposal to change the status of Curtin CTR to RA2 will enable Defence to use the Defence aerodrome more effectively for a variety of Defence flying platforms. The change of status also enables Defence to provide scalable airspace management procedures, dependant on activities, including a Class D service when required. The lateral and vertical dimensions will remain unchanged. The change of airspace status is not expected to have any discernible impact to civil operators.

    NOTAM

    YBBB/RXXX Curtin

    Conditional Status: RA2

    Military Flying

    Lateral Limits: 172710S 1234151E – 172910S 1240154E – then along the clockwise arc of a circle radius 12NM centre 173520S 1235107E (CIN/DME) – 174318S 1240032E – 174022S 1235351E – 173650S 1233838E – then along the clockwise arc of a circle radius 12NM centre 173520S 1235107E (CIN/DME) – 172710S 1234151E

    Vertical Limits: SFC-3500

    Hours of Activity: NOTAM

    Controlling Authority: Defence JACC

    The proposal to disestablish R801 and replace with segregated airspace volumes will enable Defence to activate only those portions of airspace required for proposed activities. Defence currently partially activates R801 or applies for TRA when operating out of Curtin aerodrome to ensure civil operators are provided access to Derby aerodrome. The new divisions of airspace proposed will enable Defence to continue to provide these efficiencies but as a permanent solution which is available on aeronautical charts. The following key aspects are noted (airspace depiction below):

    1. R801 lateral boundary split between north and south (resulting in two RA) following principles utilised in recent years to allow scalable activation providing improved airspace efficiencies in and around Derby.
    2. Lower vertical limit raised to A015 to enable improved access to civil operators involved in helicopter muster operations and access to Derby.
    3. DXXXA established and always activated coincidentally with RXXXA to provide situational awareness to civil operators that Defence activities are occurring and increased military flying activity can be expected in the airspace.
    4. DXXXB established and only activated if Defence activities are expected to occur below A020 to provide situational awareness that increased military flying activity can be expected in the airspace.

    NOTAM

    YBBB/RXXXA

    Conditional Status: RA2

    Military Flying

    Lateral Limits: 173120S 1232517E – 172710S 1234151E - then along the counter clockwise arc of a circle radius 12NM centre 173520S 1235107E (CIN/DME) – 173650S 1233838E – 174022S 1235351E – 174318S 1240032E - then along the counter clockwise arc of a circle radius 12NM centre 173520S 1235107E (CIN/DME) – 172910S 1240154E – 173133S 1241659E - then along the clockwise arc of a circle radius 25NM centre 173520S 1235107E (CIN/DME) – 173120S 1232517E

    Vertical Limits: 1500 – 3500

    Hours of Activity: NOTAM

    Controlling Authority: DEFENCE JACC

    NOTAM

    YBBB/RXXXB

    Conditional Status: RA2

    Military Flying

    Lateral Limits: 173120S 1232517E - then along the clockwise arc of a circle radius 25NM centre 173520S 1235107E (CIN/DME) – 173133S 1241659E – 172910S 1240154E – 172710S 1234151E – 173120S 1232517E

    Vertical Limits: 1500 – 3500

    Hours of Activity: NOTAM

    Controlling Authority: DEFENCE JACC

    NOTAM

    YBBB/DXXXA

    Conditional Status: RA2

    Military Flying

    Lateral Limits: 173120S 1232517E – 172710S 1234151E - then along the counter clockwise arc of a circle radius 12NM centre 173520S 1235107E (CIN/DME) – 173650S 1233838E – 174022S 1235351E – 174318S 1240032E - then along the counter clockwise arc of a circle radius 12NM centre 173520S 1235107E (CIN/DME) – 172910S 1240154E – 173133S 1241659E - then along the clockwise arc of a circle radius 25NM centre 173520S 1235107E (CIN/DME) – 173120S 1232517E

    Vertical Limits: SFC – 1500

    Hours of Activity: NOTAM

    Controlling Authority: DEFENCE JACC

    NOTAM

    YBBB/DXXXB

    Conditional Status: RA2

    Military Flying

    Lateral Limits: 173120S 1232517E - then along the clockwise arc of a circle radius 25NM centre 173520S 1235107E (CIN/DME) – 173133S 1241659E – 172910S 1240154E – 172710S 1234151E – 173120S 1232517E

    Vertical Limits: SFC – 1500

    Hours of Activity: NOTAM

    Controlling Authority: DEFENCE JACC
